Single band transceiver

Place of Origin: Fujian China (Mainland) Talk Range: 5-10km Type: Handheld Brand Name: TYT Storage Channel: 128 Dimensions: 112X58X32mm Frequency Range: 136-174 MHz/245-246MHz/400... Model Number: TH-800 color: black &silver&red service: good packing: color gift box price: acceptable Antenna Impedance: 50Ω delivery: fast warranty: 1year Selectivity: ≥65dB ≥60db Maximum deviation: ≤ ± 5kHz weight: 220g
Unit Type: piece Package Weight: 1.0kg Package Size: 25cm x 18cm x 6cm

digital FM radio transceiver

Main Functions:

50 CTCSS code

VOX time-lapse function,

Designate communication

Multi channel scan or skip scan function

Voice prompt

Emergency alarm

Selectable squelch /VOX grade setting

LCD display/ keypad direct frequency input

Transmit time limiter

Auto keypad lock

FM radio receiver function

Dimensions: 112X58X32mm

Weight: 220g



Main Radio Parameter:

Output power: 5W

Frequency: 136-174 MHz/245-246MHz/400-470 MHz/465-520MHz

199 groups of memory channels

Channel spacing: 5, 10, 12.5,20,25,30, 50 kHz optional

Mode of operation: simplex or semi-duplex

Antenna impedance: 50Ω

Operating voltage: 7.2V DC

Working temperature: -20 to -+50° C

Occupied Bandwidth: ≤ 16KHz

Audio Response: +2dB~-10dB

Maximum deviation: ≤  5kHz

RF sensitivity: 0.2μ V

Audio distortion: ≤ 10%

Co-channel suppression: > -8dB
