Black High Definition Deep 36Bit HDMI

Place of Origin: Guangdong China (Mainland) Model Number: SX-SP07D Housing: Steel casing Color: Black Power supply: 5V 3A DC
Unit Type: piece Package Weight: 1.5kg Package Size: 42cm x 17cm x 8cm

Features:

1. HDMI TM (V.1.4 with 3D & 4KX2K)

2. Distributes 1 HDMI source to 8 HDMI Displays simultaneously.

3. Supports all the mandatory and several optional 3D formats described in HDMI 1.4 specifications

4. Supports High Definition Resolutions :4KX2K @ 24 HZ, 1080p @ 60HZ, 720p/1080i @ 120Hz

5. Supports Digital Audio Format, such as High Definition Audio support: Dolby TrueHD, and DTS-HD Master Audio

6. DC 5V Power

Specifications:
Operating Temperature Range.............. -5 to +35°C(-41 to +95°F)
Operating Humidity Range..............  5 to 90%RH (No Condensation)
Input Video Signal..............  0.5-1.0 Volts P-P
Input DDC Signal..............  5 volts p-p(TTL)
Data transfer speed rate..............  6.75Gbps(Maximum)
Video Format Supported: DTV/HDTV:
480i/576i/480P/576P/720P/1080i/1080P/4Kx2K
3D video support
HDMI Output HDMI 1.4+HDCP1.1
Support Video Color Format..............  xv-YCC/deep color 36bit
Support Audio Format..............  DTS-HD/true-HD/LPCM7.1/AC3/DTS/DSD
Power consumption..............  10watts(Maximum)
Dimension (L×W×H)..............  270x110x27.5mm
Net Weight..............  840g
